afn tuning

Post by LIMO-B5 » Fri Feb 10, 2012 9:37 pm

i currently own a b5 wagon 110bhp
so far i have ; smoothed airbox+ pipercross pannel with pd130 pipes 2 the turbo
gutted standard cat
EGR delete
looking at a frontmount

wanting advice and prices i can expect to pay 4 the following upgrades

(merc) pierberg MAF
pd130-150 turbo
turbo off the 2.5 v6 audi a4, and if it fits!
vw T4 injectors (which engine ect)
any other turbo that will improve performance
get it serviced and chiped after everything else

anything else big or small anybody can think of
+ what mods people are running and at what figures!!

many many thanks to all that reply
Thanks , lee
NO SMOK NO POKE

User avatar
Roylewaa
B3
Posts: 329
Joined: Wed Jan 18, 2012 2:46 pm
Passat model: B5 TDI 110
Location: Durham

Re: afn tuning

Post by Roylewaa » Fri Feb 10, 2012 9:41 pm

What difference is there with the mods you have already done mate?

Passat84
B1
Posts: 83
Joined: Thu May 12, 2011 9:25 pm
Passat model: B5 TDI 110 (AFN)
Location: Rotherham

Re: afn tuning

Post by Passat84 » Fri Feb 10, 2012 10:16 pm

Im also interested in this thread.....
diesel power!

User avatar
desertstorm
Site Admin
Posts: 10215
Joined: Thu Apr 19, 2007 9:11 pm
Passat model: B5.5 130 TDI AWX
Location: Cannock

Re: afn tuning

Post by desertstorm » Fri Feb 10, 2012 10:47 pm

I would do a search on the forum. Chris Adams adams24 has covered this several times. The power you can get out of these engines is really determined by how deep your pockets are.
I don't see anywhere in your list a clutch or brake upgrades.
it's quite easy to get 170bhp with injector changes a vnt17 PD130 turbo and a change to the pump. It seems if you make the right mods with injectors and turbo and balance air and fuel improvements you can get very good improvements without having to chip the car.
Waits for chris to come along :D

Karl.
Gone but will never be forgotten
207Bhp 347Lb/ft 14.9 seconds 93mph
The build topic viewtopic.php?f=5&t=56110

The new 382bhp Audi viewtopic.php?f=5&t=70765

LIMO-B5
B1
Posts: 68
Joined: Fri Jul 22, 2011 8:50 pm
Passat model: B5 TDISE

Re: afn tuning

Post by LIMO-B5 » Sat Feb 11, 2012 7:33 pm

think im gona go 4 the 130 turbo, 216 injectors and an 11mm fuel pump
just depends what i can afford .
NO SMOK NO POKE

adamss24
UKPassat's Possie
Posts: 3883
Joined: Fri Feb 15, 2008 7:53 am

Re: afn tuning

Post by adamss24 » Sat Feb 11, 2012 8:55 pm

LIMO-B5 wrote:think im gona go 4 the 130 turbo, 216 injectors and an 11mm fuel pump
just depends what i can afford .
PD 130 turbo and 0.216 nozzles are too small for true 11mm pump. The 10mm pump you have is good for over 170-180 Bhp. The 11mm pump is very rare, much easier to get a 11mm pump head from Transit or renault vans. Couple that head with a de43 cam plate and you'll have plenty fuel for 200 Bhp. I would look at different nozzles if you aim for 200 Bhp, Bosio race 520 or Power Plus 520 are very good. Chipping the AFN ecu is a black art really, the difficult part is de-soldering the old chips and soldering the new sockets in. There are tuners who solder the chips directly onto the PCB but i would not recommend it if you're planning to further tune the engine by adding intercoolers and such.
The v6 tdi turbo won't fit easily, it's big and most likely will hit the chassis rail if you're using the stock exhaust manifold. You could use a AHU manifold on which some gifted welder can TIG weld a t25 flange (plenty on ebay for only £15) which would allow for more air. The easiest turbo swap is the bv43 as it's plug and play on afn manifold and engine with no need for additional components . Another popular upgrade is a gt1752 hybrid which you can make by using the gt1749VA hotside and the GT2052v compressor and wheel. That will get on boost quicker than the gt2052 and flow almost as much air.
Nozzles, turbo and remap will keep you plenty busy for a while but- power is addictive- so you'll get used to it pretty quick ! Set your goals from the beginning and you won't go far wrong. The clutch will complain regardless of which turbo you'll use as it's already at it's torque limits so getting a upgraded one is a must- not cheap for the longitudinal engines. Sachs SRE is highly recommended.

LIMO-B5
B1
Posts: 68
Joined: Fri Jul 22, 2011 8:50 pm
Passat model: B5 TDISE

Re: afn tuning

Post by LIMO-B5 » Sun Feb 12, 2012 7:14 pm

to be honest my budget is basicly around 3p lol
i would profer bolt on parts!
im not after pushing the car to its limits 150-170bhp would be perfect, liven it up a bit

what can u suggest to get that?
cheapest way being best,
cheers again, lee
NO SMOK NO POKE

User avatar
Adam
UKPassat's Possie
Posts: 5202
Joined: Sun Nov 28, 2010 7:22 pm
Passat model: B5.5 1.8T Wagon
Location: Oxfordshire

Re: afn tuning

Post by Adam » Sun Feb 12, 2012 7:50 pm

LIMO-B5 wrote:to be honest my budget is basicly around 3p lol
i would profer bolt on parts!
im not after pushing the car to its limits 150-170bhp would be perfect, liven it up a bit

what can u suggest to get that?
cheapest way being best,
cheers again, lee
Sell up and buy a V6 TDi, other than that you'll struggle to even do the uprated clutch you'll need before you even get round to uping the power :lol:

Small budget tuning is really a lost art, gone are the days you can play with the carb and bolt a plywood scoop to your bonnet for cold air, Stuff nowadays costs and with big power gains to be had there is a bigger picture that you haven't even mentioned yet................. Brakes.

LIMO-B5
B1
Posts: 68
Joined: Fri Jul 22, 2011 8:50 pm
Passat model: B5 TDISE

Re: afn tuning

Post by LIMO-B5 » Mon Feb 13, 2012 9:07 pm

sorted 4 brakes got some from a vr5
next 2 new pads n discs
powdercoated calipers,
did a swap on some alloys :wink:
